Combi Eco 20
Combi Eco 20
FabricAir® Combi Eco 20 is a permeable, flame-retardant, Oeko-Tex 100 certified fabric made from dope dyed yarn. It is a strong and durable fabric; machine washable and retains its dimensions after washing (max. 0,5% shrinkage). The permeability is uniform (max. 5% variation) and achieved by thermo-fixation. The color is deeply embedded within the yarn, making it more resistant to fading, washing and UV exposure. The production of this fabric is more sustainable, because chemical consumption and oxygen demand, water and energy consumptions are lower.
- Sustainable
- Permeable
- 5 year warranty
- Flame retardant fibers
- Washable
Standard colors
All our fabrics come in standard colors. Choose the one that would either blend with your interior or could become a design statement.
White 3000
Blue 3001
Gray 3003
Black 3004
Light gray 3006
Available colors and patterns
Your fabric ducts can look the way you want them. Below are the options that can be adapted to your specific needs.
- Coloring by Surface Print
- Seamless pattern
- Artwork, print
- Lettering, print
- Logos, print
Combi Eco 20 data sheet
Fabric type
Polyester
Dope dyed yarns
Weight
260 (±7%) g/m²
EN ISO 12127:1997
Thickness
0,40 mm
EN ISO 5084:1996
Permeability
40 (±5%) m³/m²/h at 120 Pa
EN ISO 9237:1995
Strength - Warp
2400 N
EN ISO 13934-1
Strength - Weft
700 N
EN ISO 13934-1
Shrinkage
0,5 % Max.
EN ISO 5077
Heat resistance - continuous
from -40 to +140°C
Heat resistance - softening
+240°C
EN 13501-1:
B-s1, d0
EN 13501-1
UL 723:
Yes
UL 723
ULC S102.2:
Yes
DS 428
Yes
Fire retardant:
M1
NF P 92-507
Cleanrooms:
Class 4
EN ISO 14644-1
UL 2518:
Yes
UL 2518
OEKO-TEX®:
Yes
OEKO-TEX® Standard 100
All-in-One:
Yes
360° hoops:
Yes
Disclaimer
FabricAir® believes that all data, statements, technical information, etc. (certificates), listed in this Technical Data Sheet regarding the product and the use of the product are accurate and reliable. However, the product will only be covered by FabricAir®’s guarantees or warranty if the final use for the product has been approved by FabricAir® in writing. No representative is authorized to approve the final use of the product on behalf of FabricAir®.
